Description
THE ESSENCE OF SUPERMOTARD RIDING
The DR-Z400SM welcomes you to the exhilarating world of SuperMoto riding with cutting-edge dual-purpose bike design and stylish, functional top-grade equipment that captures the essence of free-spirited street riding pleasure. The Suzuki DR-Z400SM is a street-legal bike for serious dirt bike enthusiasts. It’s not uncommon to take the SuperMoto down twisty forest trails as well as tight canyon corners. Its 398cc liquid-cooled, four-stroke engine provides strong low-rpm torque and crisp throttle response for any of these occasions. The key difference between the DR-Z400SM and the DR-Z400S is the inverted forks. Inverted front forks contribute to less unsprung weight and improved overall handling. Fun to ride whatever street, avenue or highway you’re headed for.
SUZUKI PROTECTION PLAN
Suzuki Protection Plan is a comprehensive plan that covers all mechanical, electrical and computer systems on your Suzuki Motorcycle or ATV. Ask your local Authorized Dealer about Suzuki Protection Plan for extra peace of mind.
A COMPACT DESIGN
Suzuki’s SuperMotard model based on DR-Z400S – combines Supermotard style and features in a narrow, lightweight street-legal package.
STRONG, TRACTABLE POWER
Lightweight, 398cc, DOHC, liquid-cooled, dry-sump engine produces strong, tractable power. Compact, four-valve cylinder head has 36mm intake valves, 29mm exhaust valves, narrow 28-degree included valve angle, and shim-under-bucket valve adjustment system.
ELECTRIC START
Simple electric starting is powered via a lightweight starter motor with an automatic mechanical decompression system.
SMOOTH THROTTLE RESPONSE
Led by a six-liter air box, the Mikuni™ 36mm carburetor incorporates a deceleration enricher circuit to help provide smooth throttle response when accelerating or engine braking.
TRANSMISSION
Compact, five-speed transmission utilizes a cable-operated clutch with a separate magnesium outer cover for simplified clutch maintenance.
STRONG BRAKING PERFORMANCE
Strong braking performance is supplied by a front disc brake with a large 300mm floating-type rotor and dual-piston calliper, plus a 240mm rear disc brake with single-piston calliper.
SHOWA INVERTED FRONT FORK
Long travel, Showa inverted front fork is derived from a RM250 and features adjustable compression/rebound damping and a special coating on inner tube surfaces for smooth action.
REAR SHOCK ABSORBER
A fully adjustable rear shock absorber with high/low-speed compression damping adjuster and a tapered RM-inspired aluminum swingarm combine for precise rear wheel control.
RENTHAL TAPERED HANDLEBAR
Renthal tapered aluminum handlebar has an aggressive look, reduces vibration, and has a great bend for spirited riding.
CHROME-MOLY STEEL FRAME
Chrome-moly steel frame tuned for Supermotard style riding is torsionally strong with minimal weight. The backbone tube, front down tube, and steering head gussets form the dry-sump engine oil tank.
WIDE ALUMINUM RIMS
Wide, blue or black anodized RK Excel aluminum rims with stainless steel spokes are fitted with sporty radial tires: 120/70-R17 front and 140/70-R17 rear.
DIGITAL INSTRUMENT CLUSTER
Compact, digital instrument cluster includes speedometer, odometer, twin-trip meters with addition/subtraction capability, clock, and stopwatch functions.
LIGHTING
On-road legal lighting includes bright 60/55-watt halogen headlight, compact tail/stoplight, lightweight, rubber-mounted turn signals, and horn.
ADDITIONAL FEATURES
A pouch on the rear fender carries the tool kit, owner’s manual, or other cargo.
SPECIFICATIONS
| Type | 4-stroke, liquid-cooled, single cylinder, DOHC |
| Displacement | 398cc |
| Bore x Stroke | 90.0mm x 62.6mm (3.5in x2.5in) |
| Compression Ratio | 11.3 : 1 |
| Fuel System | Carbureted |
| Starter | Electric |
| Lubrication | Dry-Sump |
| Ignition | Electronic ignition (CDI) |
| Transmission | 5-speed constant mesh |
| Length | 2225 mm (87.6 in) |
| Width | 855 mm (33.7 in) |
| Height | 1200 mm (47.2 in) |
| Wheelbase | 1460 mm (57.5 in) |
| Seat Height | 890 mm (35.0 in) |
| Curb Mass | 146 kg (321 lbs) |
| Suspension Front | Telescopic, coil Spring, oil damped |
| Suspension Rear | Link type, coil spring, oil damped |
| Brakes Front | Disc |
| Brakes Rear | Disc |
| Tires Front | 120/70R17M/C 58H, tube type |
| Tires Rear | 140/70R17M/C 66H, tube type |
| Fuel Tank | 10.0L (2.6 US gal) |
12 Month unlimited mileage limited warranty
