Kimpex Piston Replacement Ring Set (293984)
Kimpex Piston Replacement Ring Set (293984)
Kimpex Piston Replacement Ring Set (293984)
Kimpex Piston Replacement Ring Set (293984)
Kimpex

Kimpex Piston Replacement Ring Set (293984)

In stock - 10 items available
SKU: 293984
(0)
$37.99
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa
Piston and Ring Installation:
  • Remember never install chrome rings in chrome plated, nikasil or electrofusion cylinders.
  • Prior to installation, fit each ring into the cylinder bore and measure the end gap to eliminate the chance of ring butting. Acceptable gap range is .010 to .025. If gap is inadequate, carefully file to the recommended specs. See “Piston Clearance Guide”. Clean and lubricate all moving parts with 10W30 oil.
  • Install pistons with the arrow pointing to the exhaust side of the engine (except for few models Polaris where the arrow points toward the magneto side).
  • Install circlips carefully without forcing, bending or turning them. Be sure they seat properly in the grooves and position the openings down.
  • Install rings onto matching pistons. Lubricate and check to be sure the end gaps can be completely closed around the locating pins.
  • Install new base gaskets, compress rings and carefully slide the cylinders down into position. Before installing the cylinder heads, rotate the crankshaft by hand to make sure pistons and rings move freely into cylinder.

Vehicle Fitment

35 Vehicles
Type Make Model Year
  • ATV POLARIS Trail Blazer 250 2X42000-2006
  • ATV POLARIS Xplorer 250 4X4 2 stroke2000-2002
  • SNOWMOBILE POLARIS 500 Classic Edge ES/R L/C 121"2004-2006
  • SNOWMOBILE POLARIS 500 SKS1995
  • SNOWMOBILE POLARIS 500 SP1989, 1992
  • SNOWMOBILE POLARIS 500 WideTrak LX L/C 156"2010-2011
  • SNOWMOBILE POLARIS Indy 500 Carb L/C 121"1992
  • SNOWMOBILE POLARIS Indy 500 Classic Deluxe 133,5"1992
  • SNOWMOBILE POLARIS Indy 500 Classic Edge ES/R L/C 121"2002
  • SNOWMOBILE POLARIS Indy 500 Classic ES/R L/C 121"1994-1997, 1999-2001
  • SNOWMOBILE POLARIS Indy 500 Classic L/C 121"1989-1991, 1993, 1998
  • SNOWMOBILE POLARIS Indy 500 Classic Touring ES/R L/C 133,5"1993-1994, 1996-2002
  • SNOWMOBILE POLARIS Indy 500 Classic Touring ES/R L/C 133"2003
  • SNOWMOBILE POLARIS Indy 500 Edge 121"2004
  • SNOWMOBILE POLARIS Indy 500 Edge L/C 121"2001-2003, 2005-2006
  • SNOWMOBILE POLARIS Indy 500 EFI L/C 121"1993-1997
  • SNOWMOBILE POLARIS Indy 500 L/C 121"1989-1991, 1995-2002, 2005-2006
  • SNOWMOBILE POLARIS Indy 500 RMK EFI L/C 133,5"1996
  • SNOWMOBILE POLARIS Indy 500 RMK L/C 133,5"1996-1999
  • SNOWMOBILE POLARIS Indy 500 SKS EFI L/C 133,5"1992-1996
  • SNOWMOBILE POLARIS Indy 500 SKS L/C 133,5"1989, 1991, 1996-1997
  • SNOWMOBILE POLARIS Indy 500 SKS L/C 133"1990
  • SNOWMOBILE POLARIS Indy 500 Special EFI L/C 121"1992
  • SNOWMOBILE POLARIS Indy 500 Special L/C 121"1990-1991
  • SNOWMOBILE POLARIS Indy 500 SPX EFI L/C1992
  • SNOWMOBILE POLARIS Indy 650 L/C 121"1989
  • SNOWMOBILE POLARIS Indy 650 SKS L/C 133,5"1989
  • SNOWMOBILE POLARIS Indy Storm 800 L/C 121"1994-1995
  • SNOWMOBILE POLARIS Indy Storm 800 SKS L/C 133,5"1994-1995
  • SNOWMOBILE POLARIS Indy Trail Wide Trak 488 F/C 156"1990
  • SNOWMOBILE POLARIS Indy Wide Trak 156"1991-1993
  • SNOWMOBILE POLARIS Indy Wide Trak LX 156"1994-1998, 2001
  • SNOWMOBILE POLARIS Indy Wide Trak LX ES/R L/C 156"2000, 2002-2003
  • SNOWMOBILE POLARIS Wide Trak LX 500 ES/R L/C 156"2004-2009
  • SNOWMOBILE POLARIS WideTrak LX2012-2015
